Brand: Widia / Part #: 2022340
Item #: 99728511
Brand: Widia
Model #: 2022340
Product Specifications
| Thread Type | External |
| Hand of Holder | Right Hand |
| Compatible Insert Size Code | 2 |
| Shank Width/Diameter (mm) | 8.00 |
| Toolholder Style | NL |
| Insert Compatibility | LT11ER |
| Coolant Entry Style Code | 0-Without Coolant |
| Insert Holding Method | Screw |
| Shank Height (mm) | 8.00 |
| Shank Length (mm) | 118.500 |
| Overall Length (mm) | 136.0000 |
| Series | LT |
| Multi-use Tool | No |
| Cutting Tool Application | Threading |
| Head Length (mm) | 17.50 |
| Maximum Depth of Cut (mm) | 4.76 |
| Adjustable Overhang | Yes |
| Back of Bar to Cutting Edge (mm) | 11.00 |
| Center to Cutting Edge (mm) | 4.00 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Inscribed Circle (mm) | 6.35 |
| Primary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Super-alloys & Titanium; Steel |
| Primary Workpiece Material Code | P; S; K; M; N |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | NL82R |
| Style | LT |
| Coolant Through | No |
