1″ Dia. × 1″ Shank × 1-1/8″ DOC × 6″ OAL, Carbide Uncoated, 2 Flute, 37°|CW Helix, Round, External , Ballnose End Mill
Item #: WK402864293
Brand: Widia
Model #: 2864293
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1″ |
| Usable Length (LU) | 3-1/4″ |
| Connection Diameter Machine Side (DCONMS) | 1″ |
| Applicable Material | Aluminum / Non-Ferrous Materials |
| Depth of Cut Maximum (APMX) | 1-1/8″ |
| Corner Radius (RE) | 1/2″ |
| Overall Length (OAL) | 6″ |
| Tool Type | Center Cut|Single-End |
| Cutting Edge Material | Carbide |
| End Shape | Ball Nose |
| Coating | Uncoated |
| Coolant Supply Property (CSP) | External |
| Flute Count (NOF) | 2 |
| Style | 82-06 SEM Ball Nose Side-Cntr |
| Flute Helix Angle (FHA) | 37 Degrees|CW |
| Decimal Equivalent | 1″ |
| Shank Type | Round |
