Keo - Concave Radius Cutters Connection Type: Shank Radius (Inch): 3/16
Item #: 20084463
Brand: Keo
Model #: 905-000-032
Features and Benefits
High speed steel (HSS) provides good wear resistance. It is commonly used for general purpose applications on both ferrous and nonferrous materials.
Titanium nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Product Specifications
Concave Radius Cutters; Connection Type: Shank ; Radius (Inch): 3/16 ; Circle Diameter (Decimal Inch): 0.3750 ; Diameter of Cutter (Inch): 1 ; Cutting Width (Inch): 5/8 ; Shank Diameter (Inch): 3/4
| Connection Type | Shank |
| Radius (Inch) | 3/16 |
| Circle Diameter (Decimal Inch) | 0.3750 |
| Diameter of Cutter (Inch) | 1 |
| Cutting Width (Inch) | 5/8 |
| Shank Diameter (Inch) | 3/4 |
| Overall Length (Inch) | 3-1/2 |
| Material | High Speed Steel |
| Finish/Coating | TiN |
| Relief Style | Form Relieved |
| Number of Teeth | 6 |
| Weldon Flat | Yes |
