Brand: Widia / Part #: 2498713
Item #: 94500477
Brand: Widia
Model #: 2498713
Product Specifications
| Insert Style | PGU |
| Insert Size Code | 2 |
| Insert Size | 2 |
| Insert Material | Carbide |
| Manufacturer Grade | TN7535 |
| Cutting Width (Decimal Inch) | 0.0830 |
| Maximum Depth of Cut (Decimal Inch) | 0.3559 |
| Insert Holding Method | Clamp |
| Insert Hand | Neutral |
| Corner Radius (Decimal Inch) | 0.0080 |
| Lead Angle | 22.000 |
| Rake | Positive |
| Multi-use Tool | Yes |
| Cutting Tool Application | Grooving |
| Series | PGU |
| Coating Process | CVD |
| Overall Length (Decimal Inch) | 0.3559 |
| Primary Workpiece Material | Cast Iron; Steel |
| Primary Workpiece Material Code | P; K |
| Ansi Code | 123567320 |
| Iso Code | 123567320 |
| Relief Angle | 22 |
| Manufacturers Catalog Number | 123567320 |
| Insert Thickness (Decimal Inch) | 0.1378 |
| Chip Breaker | LGN0 |
| Insert Seat Size | 2 |
| Insert Height (Decimal Inch) | 0.1378 |
| Full Radius | No |
| Coating Classification | CVD |
| Hole Diameter (Decimal Inch) | 0.0000 |
| Coating/Finish | TiCN; TiN; Al2O3 |
| Number Of Cutting Edges | 1 |
| Single Or Double End | Single |
| For Use With | Grooving |
