Brand: Widia / Part #: 5873224
Item #: 09880717
Brand: Widia
Model #: 5873224
Product Specifications
| Minimum Cutting Diameter (mm) | 100.00 |
| Maximum Cutting Diameter (mm) | 100.00 |
| Maximum Depth of Cut (mm) | 10.00 |
| Arbor Hole Diameter (mm) | 32.00 |
| Compatible Insert Size Code | SD..1204.. |
| Maximum Ramping Angle | 0 |
| Cutter Style | M690 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Positive |
| Series | M690 |
| Maximum Body Diameter (mm) | 96.40 |
| Overall Height (Mm - 5 Decimals) | 50.00000 |
| Keyway Width (mm) | 14.48 |
| Hub Diameter (mm) | 78.000 |
| Maximum RPM | 15800.000 |
| Tool Application | Milling; Slotting |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Number of Adjustable Pockets | 0 |
| ISO Number | 12396955200 |
| Complete Insert Compatibility | SD__1204___ |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | 12396955200 |
| Coolant Through | No |
| Number Of Cutter Inserts | 10 |
| Number Of Flutes | 10 |
