Brand: Widia / Part #: 6172963
Item #: 97473011
Brand: Widia
Model #: 6172963
Product Specifications
| Thread Size (Inch) | 1-3/4-5 |
| Chamfer | Modified Bottoming |
| Thread Limit | H8 |
| Class Of Fit | 2B |
| Number Of Flutes | 5 |
| Material | High Speed Steel |
| Threads per Inch | 5 |
| Thread Direction | Right Hand |
| Flute Direction | Right Hand |
| Coating/Finish | Black Oxide |
| Coolant Through | No |
| Thread Length (Decimal Inch) | 1.9700 |
| Overall Length (Decimal Inch) | 8.6600 |
| Thread Depth (Decimal Inch) | 4.2500 |
| Thread Pitch (Decimal Inch) | 0.2000 |
| Thread Standard | UNC |
| Material Grade | WP49EG |
| Shank Diameter (Decimal Inch) | 1.4173 |
| Square Size (Decimal Inch) | 1.1420 |
| Material Application | Stainless Steel; Cast Iron; Steel |
| Series | VTSFT-TC |
