Brand: Ingersoll Cutting Tools / Part #: 5812897
Item #: 94552361
Brand: Ingersoll Cutting Tools
Model #: 5812897
Product Specifications
| Milling Tip Type | High Feed |
| Milling Tip Style | 48A_T_RA |
| Maximum Depth of Cut (Decimal Inch) | 0.0470 |
| Cutting Diameter (Decimal Inch) | 1.0000 |
| Tool Material | Carbide |
| Manufacturer Grade | IN2006 |
| Insert Hand | Right Hand |
| Chipbreaker | None |
| Series | 48A_T_RA |
| Coating Process | PVD |
| Corner Radius (Decimal Inch) | 0.1450 |
| Primary Workpiece Material | Hard Material; Stainless Steel; Super-alloys & Titanium; Steel |
| Primary Workpiece Material Code | P; S; H; M |
| Thread Size | T15 |
| Manufacturers Catalog Number | 48A-1004TURA20 |
| Overall Length (Decimal Inch) | 0.9840 |
| Coolant Through | No |
| Included Angle Degree | 90 |
| Depth Of Cut | 0.0470 |
| Coating/Finish | TiAlN |
| Length Of Cut (Decimal Inch - 4 Decimals) | 0.9840 |
| Number Of Flutes | 6 |
