Brand: Widia / Part #: 2829892
Item #: 59869339
Brand: Widia
Model #: 2829892
Product Specifications
| Minimum Bore Diameter (Decimal Inch) | 0.2960 |
| Maximum Bore Depth (Decimal Inch) | 1.0000 |
| Toolholder Style | FCBI |
| Tool Material | Steel (Head); Solid Carbide (Shank) |
| Insert Compatibility | TD.. |
| Shank Diameter (Decimal Inch) | 0.2500 |
| Hand of Holder | Right Hand |
| Overall Length (Decimal Inch) | 6.0000 |
| Compatible Insert Size Code | 130805 |
| Insert Holding Method | Screw |
| Compatible Insert Shape | Triangle |
| Insert Included | No |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Rake Angle | 5.000 |
| Lead Angle | 90.000 |
| Series | FCBI |
| Insert Inscribed Circle (Decimal Inch) | 0.1600 |
| Compatible Insert Thickness (Decimal Inch) | 0.0470 |
| Multi-use Tool | Yes |
| Cutting Tool Application | Turning; Boring |
| Back of Bar to Cutting Edge (Decimal Inch) | 6.0000 |
| Center to Cutting Edge (Decimal Inch) | 0.1560 |
| Primary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel |
| Primary Workpiece Material Code | P; K; M; N |
| Multi-Use Application | External Turning; Internal Turning; Turning; Boring |
| Number of Inserts Used on Toolholder | 1 |
| Insert Thickness (Decimal Inch) | 0.0470 |
| Coolant Hole Diameter (Decimal Inch) | 0.0470 |
| Coolant Hole Diameter (mm) | 1.19 |
| Insert Size | 130805 |
| Body Diameter | 0.2500 |
| Model Number | FCBI-250-6-0R 0.250 |
| Insert Style | TD.. |
| Coolant Through | Yes |
