Brand: Ingersoll Cutting Tools / Part #: 5873199
Item #: 67311878
Brand: Ingersoll Cutting Tools
Model #: 5873199
Product Specifications
| Insert Style | AOMT |
| Insert Size Code | 120404 |
| Insert Material | Carbide |
| Manufacturer Grade | IN1030 |
| Inscribed Circle (Decimal Inch) | 0.3250 |
| Corner Radius (Inch) | 1/64 |
| Insert Hand | Right Hand |
| Series | AOMT |
| Coating Process | PVD |
| Maximum Depth of Cut (Decimal Inch) | 0.4900 |
| Number Of Cutting Edges | 2 |
| Insert Shape | Parallelogram |
| Rake | Positive |
| Primary Workpiece Material | Stainless Steel; Super-alloys & Titanium; Steel |
| Primary Workpiece Material Code | P; S; M |
| Ansi Code | AOMT120404R I |
| Manufacturers Catalog Number | AOMT120404R I IN1030 |
| Cutter Series Compatibility | 12V1X; 22J3X; 2J1X; 12J1X; 22N3X |
| Chip Breaker | None |
| Cutting Direction | Right Hand |
| Shape | Parallelogram |
| Length of Cut (mm) | 12.4500 |
| Insert Holding Method | Screw |
| Coating Classification | PVD |
| Single or Double Sided Insert | Single |
| Coating/Finish | TiCN |
| Included Angle Degree | 85 |
| Width (Decimal Inch - 4 Decimals) | 0.3250 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1900 |
| Multi-Use Tool | Yes |
| Length (Decimal Inch - 4 Decimals) | 0.5730 |
