Brand: Widia / Part #: 2027472

Brand: Widia / Part #: 2027472


Item #: 93303147
Brand: Widia
Model #: 2027472

Product Specifications

Insert Style CCMT
Insert Shape Code C
Insert Size Code 432
Insert Shape Diamond
Coating/Finish Uncoated
Manufacturer Grade THM
Corner Radius (Decimal Inch) 0.0315
Insert Material Carbide
Hole Diameter (Decimal Inch) 0.2165
Maximum Depth of Cut (Decimal Inch) 0.2539
Inscribed Circle (Decimal Inch) 0.5000
Insert Holding Method Screw
Insert Hand Neutral
Insert Thickness (Decimal Inch) 0.1875
Clearance Code C
Tolerance Code M
Included Angle 80.00
Relief Angle 7.000
Series CCMT
Coating Process Uncoated
Rake Positive
Wiper Edge No
Insert Length (Decimal Inch) 0.5077
Number Of Cutting Edges 2
Primary Workpiece Material Super-alloys & Titanium
Primary Workpiece Material Code S
Secondary Workpiece Material Non-Ferrous Metal
Secondary Workpiece Material Code N
Ansi Code CCMT432
Iso Code CCMT120408
Manufacturers Catalog Number CCMT432
Cutting Direction Neutral
Coating Classification Uncoated
Chip Breaker None
Style CCMT
Width (Decimal Inch - 4 Decimals) 0.5000
Multi-Use Tool Yes
Full Radius No
Multi-Use Application External Turning; Internal Turning
$11.89
