Brand: Widia / Part #: 3655893
Item #: 98036767
Brand: Widia
Model #: 3655893
Product Specifications
| Internal or External | External |
| Hand of Holder | Left Hand |
| Maximum Groove Width (Decimal Inch) | 0.0940 |
| Minimum Groove Width (Decimal Inch) | 0.0937 |
| Toolholder Style | WMTCL |
| Tool Material | Steel |
| Insert Holding Method | Clamp |
| Compatible Insert Size Code | S094 |
| Insert Compatibility | WMTS094I2BP02PT |
| Shank Height (Inch) | 1/2 |
| Shank Height (Decimal Inch) | 0.5000 |
| Shank Length (Decimal Inch) | 3.3100 |
| Shank Width/Diameter (Decimal Inch) | 0.5000 |
| Shank Width/Diameter (Inch) | 1/2 |
| Series | WMT |
| Overall Length (Decimal Inch) | 4.5000 |
| Cutting Tool Application | Grooving; Cut-Off; Turning |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.5000 |
| Head Height (mm) | 18.570 |
| Head Length (Decimal Inch) | 1.1890 |
| Primary Workpiece Material | Universal |
| Coolant Through | No |
