Brand: Tritan / Part #: UCPSS211-32SS

Brand: Tritan / Part #: UCPSS211-32SS


Item #: 96743968
Brand: Tritan
Model #: UCPSS211-32SS

Product Specifications

Bearing Insert Type Wide Inner Ring
Inside Diameter (Inch) 2
Outside Diameter 218.0000
Bearing Bore Diameter (Decimal Inch) 2.0000
Bolt Hole (Center-to-center) 171 mm
Base to Bore Centerline (mm) 63.50
Bolt Size (Decimal Inch) 0.6250
Housing Material Stainless Steel
Overall Length (mm) 218.0000
Overall Width 126.0000
Overall Height (Mm - 5 Decimals) 55.60000
Lock Type Set Screw
Static Load Capacity 5248.00
Number Of Bolts 2
Dynamic Load Capacity (Lb.) 8117.000
Maximum RPM 3300.000
Series UCPSS
Distance Between Mounting Hole Centers 2-3/16
Distance Between Base And Center 2-1/2
Insert Material Stainless Steel
Maximum Bore Diameter (Inch) 2
Flange Height (Decimal Inch) 4.9600
Shaft Size (mm) 50.80
Load Capacity (Lb. - 3 Decimals) 5248.000
Distance Between Mount Hole Centers (mm) 171.00
$528.90
