NMTB30SM-075-131 BT30 Shell Mill Adapter, 3/4" Pilot x 1.31" Projection

Item #: GM30NMTB30SM075
Manufacturer: Briney
Mfg #: NMTB30SM-0

Technical Specifications:
*Arbor Thread: 3/8-24 UNF-2B *Base Coupling OD: 1.750 *Body Length: 1.579 *Brand Name: Briney *Flange Diameter: 1.810 *Gage Length: 1.312 *Model Number: NMTB30SM-075-131 *Overall Length: 4.688 *Pilot Diameter: 3/4 *Pilot Length: .688 *Shank: NMTB30 *Shell Mill Pilot Size: .750 *Thread Size: 1/2-13 UNC-2B *Type: Shell Mill Adapter *Weight: 2.0 lbs

Description:
*.0002" concentricty or less from taper shank to arbor diameter *Black oxide prior to finish grind *Holder is drilled thru for thru coolant - recommend screw from facemill manufacturer for proper plumbing if coolant needs to be plumbed thru cutter

Shipping Info:
*Actual Weight - 1.6800 *Dimensions - Height: 3.25 Length: 5.75 Width: 3.50
