Brand: Widia / Part #: 4169663

Brand: Widia / Part #: 4169663


Item #: 23152341
Brand: Widia
Model #: 4169663

Product Specifications

Insert Style WMTC
Insert Size Code 125N
Insert Material Carbide
Manufacturer Grade WU25PT
Cutting Width (Decimal Inch) 0.1250
Cutting Width (Inch) 1/8
Insert Holding Method Clamp
Lead Angle Direction Neutral
Insert Hand Neutral
Lead Angle 0.000
Relief Angle 5.000
Corner Radius (mm) 0.17
Corner Radius (Decimal Inch) 0.0070
Chipbreaker CM
Multi-use Tool No
Cutting Tool Application Cut-Off
Series WMTC
Coating Process PVD
Overall Length (Decimal Inch) 1.0000
Primary Workpiece Material Super-alloys & Titanium
Primary Workpiece Material Code S
Secondary Workpiece Material Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel
Secondary Workpiece Material Code P; K; M; N
Ansi Code WMTC125N00CMW17
Iso Code WMTC125N00CMW17
Cutting Height (Decimal Inch) 0.1850
Manufacturers Catalog Number WMTC125N00CMW17
Insert Seat Size 3
Cutting Direction Neutral
Maximum Depth of Cut (Decimal Inch) 1.0000
Coating Classification PVD
Insert Width (Decimal Inch) 0.0940
Overall Width (Decimal Inch - 4 Decimals) 0.1250
Coating/Finish AlTiN
Single Or Double End Double
