PNMT 0602-TN IC830
Item #: EH5669235
Brand: Iscar
Model #: 5669235
| Product Specifications | |
|---|---|
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | |
| Grade | IC830 |
| Application | | Chamfering & Bottom Deburring | Countersinking | Milling Inserts | Slanted Shoulder & Chamfer | |
| Maximum Feed per Tooth (fz(max)) | 0.0047 ″/tooth |
| Cutting Edge Length (L) | 0.091″ |
| Cutting Direction (HAND) | Right Hand |
| Corner Radius (RE) | 0.0079″ |
| Cutting Edge Material | Carbide |
| Inscribed Circle Diameter (IC) | 0.236″ |
| Minimum Feed per Tooth (fz(min)) | 0.0027 ″/tooth |
| Insert Thickness (S) | 0.083″ |
| Cutting Edge Effective Length (LE) | 0.059″ |
| Insert Included Angle (EPSR) | 90 Degrees |
| Measurement Type | Inch |
| Coating | AlTiN+TiN |
| Body Material | Carbide |
