SNMG 432-EM-R IC806
Item #: EH5510106
Brand: Iscar
Model #: 5510106
| Product Specifications | |
|---|---|
| Applicable Material | | Hi Temp Alloys | |
| Grade | IC806 |
| Application | | Ext. 90°Square 45°Face&Turn Ap | Insert | |
| Tool Type | Turn Inserts AL, HTA Geometric |
| Insert Style | SNMG |
| Min D.O.C. | 0.118″ |
| Corner Radius (RE) | 0.0315″ |
| Depth of Cut Maximum (APMX) | 0.236″ |
| Insert Size | 432 |
| Min. Turning Feed (ft(min)) | 0.0098 ″/rev |
| Cutting Edge Length (L) | 1/2″ |
| Max. Turning Feed (ft(max)) | 0.0197 ″/rev |
| Insert Thickness (S) | 0.187″ |
| Chip Breaker Type | EMR |
| Inscribed Circle Diameter (IC) | 1/2″ |
| Measurement Type | Inch |
| Cutting Edge Material | Carbide |
| Shape | 90° Square |
| Coating | AlTiN "SUMO TEC" |
| Body Material | Carbide |
