Brand: Widia / Part #: 4169697

Brand: Widia / Part #: 4169697


Item #: 93313658
Brand: Widia
Model #: 4169697

Product Specifications

Insert Style WMTC
Insert Size Code 040L
Insert Material Carbide
Manufacturer Grade WU25PT
Cutting Width (Decimal Inch) 0.1570
Cutting Width (Inch) 5/32
Insert Holding Method Clamp
Lead Angle Direction Left Hand
Insert Hand Left Hand
Lead Angle 0.000
Relief Angle 5.000
Corner Radius (mm) 0.17
Corner Radius (Decimal Inch) 0.0070
Chipbreaker CM
Multi-use Tool No
Cutting Tool Application Cut-Off
Series WMTC
Coating Process PVD
Overall Length (Decimal Inch) 1.0000
Primary Workpiece Material Super-alloys & Titanium
Primary Workpiece Material Code S
Secondary Workpiece Material Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel
Secondary Workpiece Material Code P; K; M; N
Ansi Code WMTC040L12CM17
Iso Code WMTC040L12CM17
Cutting Height (Decimal Inch) 0.1810
Manufacturers Catalog Number WMTC040L12CM17
Insert Seat Size 4
Cutting Direction Left Hand
Maximum Depth of Cut (Decimal Inch) 1.0000
Coating Classification PVD
Insert Width (Decimal Inch) 0.1240
Overall Width (Decimal Inch - 4 Decimals) 0.1570
Coating/Finish AlTiN
Single Or Double End Double
$29.22
