Brand: Widia / Part #: 2022259

Brand: Widia / Part #: 2022259


Item #: 94027141
Brand: Widia
Model #: 2022259

Product Specifications

Insert Style CCGT
Insert Shape Code C
Insert Size Code 2151
Insert Shape Diamond
Coating/Finish TiAlN; Al2O3
Manufacturer Grade HCK10
Corner Radius (Decimal Inch) 0.0157
Insert Material Carbide
Hole Diameter (Decimal Inch) 0.1102
Maximum Depth of Cut (Decimal Inch) 0.1270
Inscribed Circle (Decimal Inch) 0.2500
Insert Holding Method Screw
Insert Hand Neutral
Insert Thickness (Decimal Inch) 0.0938
Clearance Code C
Tolerance Code G
Included Angle 80.00
Relief Angle 7.000
Series CCGT
Coating Process PVD
Rake Positive
Wiper Edge No
Insert Length (Decimal Inch) 0.2539
Number Of Cutting Edges 2
Primary Workpiece Material Non-Ferrous Metal
Primary Workpiece Material Code N
Ansi Code CCGT2151AL3
Iso Code CCGT060204AL3
Manufacturers Catalog Number CCGT2151AL3
Cutting Direction Neutral
Coating Classification PVD
Chip Breaker AL3
Style CCGT
Width (Decimal Inch - 4 Decimals) 0.2500
Multi-Use Tool Yes
Full Radius No
Multi-Use Application External Turning; Internal Turning
$12.92
