Associated Spring Raymond - 6.1mm OD, 0.97mm Wire, 22.35mm Free Length, Compression Spring - 38 Lb Spring Rating, 49.2 N Max Work Load, Music Wire
Item #: 93839256
Brand: Associated Spring Raymond
Model #: C02400380880M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 38.0000 |
| Maximum Work Load (N) | 49.20000076 |
| Solid Height (mm) | 12.04 |
| Solid Height (Decimal Inch) | 0.4740 |
| Material | Music Wire |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
