Brand: Ingersoll-Rand / Part #: 47772790001
Item #: 99824153
Brand: Ingersoll-Rand
Model #: 47772790001
Product Specifications
| Winch Type | Lifting |
| Load Rating 1st Layer | 1320 lb |
| Load Rating Mid-drum | 1320 lb |
| Load Rating Full Drum | 1320 lb |
| Drum Capacity 1st Layer | 32 ft |
| Drum Capacity Mid-drum | 105 ft |
| Number Of Speeds | Variable |
| Drum Capacity Full Drum | 190 ft |
| Winch Gear Type | Planetary |
| Line Speed 1st Layer | 20 ft/min |
| Line Speed Full Drum | 20 ft/min |
| Air Consumption | 141.00 |
| Required Pressure | 90 psi |
| Hose Size | 0.75 in |
| Brake Included | Yes |
| Body Material | Steel |
| Cable Diameter | 0.25 in |
| Cable Length | 200.000 |
| Pulling Direction | Vertical |
| Number Of Mounting Holes | 4.000 |
| Color | Yellow |
| Motor Type | Gear Motor |
| Portable | Yes |
| Overall Height | 11 in |
| Overall Length | 14.20 |
| Overall Width | 11 |
| Standards | ANSI/ASME B30.7, CE FEM Classification 1 Bm, and other 3rd party type approvals |
| Series | LS2-600R-PH6M Liftstar Air Winch |
