Recoil - M10x1.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 4-7/8 Free Coils, 10mm Overall Length, 11.95 to 12.5mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908764
Brand: Recoil
Model #: 15102MAD
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M10x1.50 |
| Overall Insert Length (mm) | 10.00 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Length to Diameter Ratio | 1D |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 11.95 |
| Maximum Outside Diameter (mm) | 12.50 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 4-7/8 |
| Maximum Locking Torque (N/m) | 6.00 |
| Minimum Break Away Torque (N/m) | 0.8000 |
| Thread Standard | Metric Coarse |
