Recoil - M8x1.25 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 7-3/8 Free Coils, 12mm Overall Length, 9.8 to 10.35mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908723
Brand: Recoil
Model #: 15083MAD
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M8x1.25 |
| Overall Insert Length (mm) | 12.00 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Length to Diameter Ratio | 1-1/2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 9.80 |
| Maximum Outside Diameter (mm) | 10.35 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 7-3/8 |
| Maximum Locking Torque (N/m) | 6.00 |
| Minimum Break Away Torque (N/m) | 0.8000 |
| Thread Standard | Metric Coarse |
