Recoil - #5-40 UNC, 1D, Stainless Steel Screw Locking Insert - 3-1/4 Free Coils, 1/8 Inch Overall Length, 0.158 to 0.173 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907493
Brand: Recoil
Model #: 13552
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #5-40 |
| Overall Insert Length (Decimal Inch) | 0.1250 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Length to Diameter Ratio | 1D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1580 |
| Maximum Outside Diameter (Decimal Inch) | 0.1730 |
| Finish/Coating | Bright |
| Number of Free Coils | 3-1/4 |
| Maximum Locking Torque (oz-in) | 75 |
| Mininum Break Away Torque (oz-in) | 13.00 |
| Thread Standard | UNC |
