Iscar - 25mm Cutting Diam, 6mm Max Depth of Cut, Modular Connection Indexable Copy End Mill - 2 Inserts, RCMT/RCCT-MO, RCMT/RCMW/RCCW-FW, RCMW/RCCW-MO Insert, ERW-M Toolholder, Through Coolant
Item #: 91120618
Brand: Iscar
Model #: 3105229
Exact Tooling IR#: 04
Features and Benefits
Modular connections allow for single end mill to accept various shank diameters without changing machine toolholding set-ups.
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 25.00 |
| Maximum Depth of Cut (mm) | 6.00 |
| Shank Type | Modular Connection |
| Modular Connection Thread Size | M12 |
| Number of Cutter Inserts | 2 |
| Insert Style | RCMT/RCCT-MO; RCMT/RCMW/RCCW-FW; RCMW/RCCW-MO |
| Toolholder Style | ERW-M |
| Series | FlexFit; MillShred |
| Overall Length (mm) | 35.00 |
| Insert Diameter (mm) | 12.00 |
| Insert Holding Method | Screw |
| Through Coolant | Through Coolant |
| Number of Flutes | 2 |
| Minimum Cutting Diameter (mm) | 13.00 |
| Head Length (mm) | 35.00 |
| Modular Connection Size | M12 |
