De-Sta-Co - 4,002 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp - 145 Max psi, 96° Bar Opening, 97.79mm Height Under Bar
Item #: 90230160
Brand: De-Sta-Co
Model #: 858-LC
Exact Tooling IR#: 04
Features and Benefits
Horizontal mounts indicate that the cylinder is mounted parallel to the clamping bar's closed position.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Horizontal |
| Holding Capacity - Inner (N) | 17800 |
| Holding Capacity - Inner (Lb.) | 4002 |
| Height Under Bar (mm) | 97.79 |
| Height Under Bar (Decimal Inch) | 3.85 |
| Bar Opening (Degrees) | 96 |
| Length Distance Between Mount Holes (mm) | 107.95 |
| Length Distance Between Mount Holes (Decimal Inch) | 4.2500 |
| Width Distance Between Mount Holes (mm) | 69.85 |
| Width Distance Between Mount Holes (Decimal Inch) | 2.7500 |
| Clamping Force - Inner (N) | 6857 |
| Clamping Force - Inner (Lb.) | 1542 |
| Bar Extension (Decimal Inch) | 4.8100 |
| Bar Extension (mm) | 122.17 |
| Overall Open Length (mm) | 322.84 |
| Overall Open Length (Decimal Inch) | 12.71 |
| Overall Closed Length (mm) | 445.01 |
| Overall Closed Length (Decimal Inch) | 17.52 |
| Overall Open Height (Decimal Inch) | 12.27 |
| Overall Open Height (mm) | 311.66 |
| Overall Closed Height (mm) | 180.85 |
| Overall Closed Height (Decimal Inch) | 7.12 |
| Outer Clamping Force (N) | 3585 |
| Outer Clamping Force (Lb.) | 806 |
| Maximum Air Pressure (psig) | 145.00 |
| Maximum Air Pressure (bar) | 10.00 |
| Mounting Hole Size (mm) | 10.41 |
| Mounting Hole Size (Decimal Inch) | 0.4100 |
| Bar Style | Solid |
| Bar End Type | Closed |
| Maximum Mechanical Advantage | 2.3:1; 4.4:1 |
| Sensor Compatibility | Round; T-Slot |
| Cylinder Bore Size (mm) | 62.99 |
| Cylinder Bore Size (Decimal Inch) | 2.4800 |
| Maximum Operating Temperature (C) | 90.00 |
| Maximum Operating Temperature (F) | 194.00 |
| Minimum Operating Temperature (F) | 14.00 |
| Minimum Operating Temperature (C) | -10.00 |
