Tritan - 3/4" ID, 3-3/4" Max OD, 11,550 Lb Max Static Cap, Male Spherical Rod End - 3/4-16 RH, 7/8" Shank Diam, 1-3/4" Shank Length, Zinc Plated Carbon Steel with Sintered Oil Impregnated Bronze Raceway
Item #: 90159401
Brand: Tritan
Model #: HM 12
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Inside Diameter (Decimal Inch) | 0.7500 |
| Inside Diameter (mm) | 19.0000 |
| Inside Diameter (Inch) | 3/4 |
| Style | Male Rod End |
| Maximum Outside Diameter (Decimal Inch) | 3.7500 |
| Maximum Outside Diameter (mm) | 95.30 |
| Maximum Outside Diameter (Inch) | 3-3/4 |
| Maximum Outside Diameter (Inch) | 3-3/4 |
| Maximum Static Load Capacity (Pounds) | 11550.0 |
| Width (Inch) | 1-3/4 |
| Width (Decimal Inch) | 1.7500 |
| Width (mm) | 44.50 |
| Thread Size | 3/4-16 |
| Material | Zinc Plated Carbon Steel |
| Shank Diameter (mm) | 22.2000 |
| Shank Diameter (Decimal Inch) | 0.8750 |
| Shank Diameter (Inch) | 7/8 |
| Raceway Material | Sintered Oil Impregnated Bronze |
| Shank Length (Decimal Inch) | 1.7500 |
| Shank Length (mm) | 44.500 |
| Thread Direction | Right Hand |
| Overall Length (Inch) | 3-3/4 |
| Overall Length (mm) | 95.3000 |
| Overall Length (Decimal Inch) | 3.7500 |
