Tritan - 3/8" ID, 2-7/16" Max OD, 3,950 Lb Max Static Cap, Female Spherical Rod End - 3/8-24 LH, 1/2" Shank Diam, 13/16" Shank Length, Zinc Plated Carbon Steel with Sintered Oil Impregnated Bronze Raceway
Item #: 90159310
Brand: Tritan
Model #: HFL 6
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Inside Diameter (Decimal Inch) | 0.3750 |
| Inside Diameter (mm) | 10.0000 |
| Inside Diameter (Inch) | 3/8 |
| Style | Female Rod End |
| Maximum Outside Diameter (Decimal Inch) | 2.4375 |
| Maximum Outside Diameter (mm) | 61.90 |
| Maximum Outside Diameter (Inch) | 2-7/16 |
| Maximum Outside Diameter (Inch) | 2-7/16 |
| Maximum Static Load Capacity (Pounds) | 3950.0 |
| Width (Inch) | 1 |
| Width (Decimal Inch) | 1.0000 |
| Width (mm) | 25.40 |
| Thread Size | 3/8-24 |
| Material | Zinc Plated Carbon Steel |
| Shank Diameter (mm) | 12.7000 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Shank Diameter (Inch) | 1/2 |
| Raceway Material | Sintered Oil Impregnated Bronze |
| Shank Length (Decimal Inch) | 0.8120 |
| Shank Length (mm) | 20.600 |
| Thread Direction | Left Hand |
| Overall Length (Inch) | 2.130 |
| Overall Length (mm) | 54.1000 |
| Overall Length (Decimal Inch) | 2.1300 |
