Brand: Ingersoll Cutting Tools / Part #: 6134747
Item #: 42612929
Brand: Ingersoll Cutting Tools
Model #: 6134747
Product Specifications
| Insert Style | NQHG |
| Insert Size Code | 250600 |
| Insert Material | Carbide |
| Manufacturer Grade | IN2504 |
| Inscribed Circle (Inch) | 1 |
| Corner Radius (Inch) | 1/2 |
| Insert Hand | Right Hand |
| Series | NQHG |
| Coating Process | PVD |
| Maximum Depth of Cut (Decimal Inch) | 0.5000 |
| Number Of Cutting Edges | 1 |
| Insert Shape | Ball Nose |
| Rake | Positive |
| Primary Workpiece Material | Hard Material; Cast Iron; Steel |
| Primary Workpiece Material Code | P; H; K |
| Ansi Code | NQHG250600R-SM |
| Manufacturers Catalog Number | NQHG250600R-SM IN2504 |
| Cutter Series Compatibility | 12A9 |
| Chip Breaker | SM |
| Cutting Direction | Right Hand |
| Shape | Ball Nose |
| Length of Cut (mm) | 12.7000 |
| Insert Holding Method | Screw |
| Coating Classification | PVD |
| Single or Double Sided Insert | Single |
| Coating/Finish | TiN; TiAlN |
| Width (Decimal Inch - 4 Decimals) | 1.0000 |
| Thickness (Decimal Inch - 4 Decimals) | 0.2440 |
| Multi-Use Tool | No |
