Circuit Breakers; Circuit Breaker Type: Miniature Circuit Breaker; Amperage: 100; Voltage: 480V, 277V; Wire Size (AWG): 12-2/0 (Aluminum)/14-2/0 (Copper); Number Of Poles: 3; Tripping Mechanism: Thermal-Magnetic; Terminal Connection Type: Lug; Phase: Sing
Item #: 93502763
Brand: Square D
Model #: EDB34100CA
Product Specifications
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 100 |
| Voltage | 480V; 277V |
| Wire Size (AWG) | 12-2/0 (Aluminum)/14-2/0 (Copper) |
| Number Of Poles | 3 |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Phase | Single |
| Breaking Capacity | 18 kA; 25 kA |
| Mount Type | Bolt-On |
| Maximum Operating Temperature F | 122.000 |
| Minimum Operating Temperature F | 32.000 |
| Overall Length (Decimal Inch) | 4.0500 |
| Overall Width (Decimal Inch - 4 Decimals) | 2.9400 |
| Overall Height (Decimal Inch) | 5.6600 |
| Standards | cULus |
| UNSPSC Code | 39121603 |
