Kennametal - Straight Shank, Series DA180, Double Angle Reamer Collet Chuck - 2.88 Inch Projection, 1/32 to 3/4 Inch Collet Capacity, 4 Inch Shank Length, Through Coolant
Item #: 85149086
Brand: Kennametal
Model #: 1015952
Exact Tooling IR#: 04
Features and Benefits
Straight shanks are used for general purpose machining and commonly have a larger diameter than taper shanks.
| Product Specifications | |
|---|---|
| Collet System | Double Angle Reamer |
| Collet Series | DA180 |
| Shank Type | Straight Shank |
| Shank Diameter (Inch) | 1-1/2 |
| Projection (Decimal Inch) | 2.8800 |
| Through Coolant | Yes |
| Minimum Collet Capacity (Inch) | 1/32 |
| Maximum Collet Capacity (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 6.8800 |
| Shank Length (Inch) | 4 |
| Shank Length (Decimal Inch) | 4.0000 |
| Hex Diameter (Inch) | 1-47/64 |
| Hex Diameter (Decimal Inch) | 1.7344 |
| Locknut Diameter (Decimal Inch) | 2.3800 |
| Float From Center (Decimal Inch) | 0.1000 |
| PSC Code | 5136 |
