Palmgren - 5-1/8" Jaw Width x 4, 4-1/2" (V-Jaw) Jaw Opening Capacity, 3-1/2" Throat Depth, Bench & Pipe Combination Vise - 1/4 to 3-1/2" Pipe Capacity, Swivel Base, Bolt Down Attachment, Cast Iron (Body), Steel (Jaw Plate)
Item #: 85142321
Brand: Palmgren
Model #: 9629503
Exact Tooling IR#: 04
Features and Benefits
Swivel vises are designed to rotate 360 degrees without moving the workpiece from the vise.
| Product Specifications | |
|---|---|
| Jaw Width (Inch) | 5-1/8 |
| Jaw Width (Decimal Inch) | 5.1250 |
| Jaw Opening Capacity (Inch) | 4; 4-1/2 (V-Jaw) |
| Jaw Opening Capacity (Decimal Inch) | 4.0000; 4.5000 (V-Jaw) |
| Throat Depth (Inch) | 3-1/2 |
| Maximum Pipe Capacity (Inch) | 3-1/2 |
| Minimum Pipe Capacity (Inch) | 1/4 |
| Base Motion Type | Swivel |
| Base Attachment Type | Bolt Down |
| Material | Cast Iron (Body); Steel (Jaw Plate) |
| Overall Length (Inch) | 16-1/2 |
| Model Number | MJ50 |
| Safety/High Visibility | No |
| Anvil | Yes |
| Overall Height (Inch) | 10-5/8 |
