Electro Hardware - #2-56, 3/4" OAL, 3/16" Across Flats, Brass Hex Female Circuit Board Standoffs - 3/16" Thread Depth, 3/4" Body Length, Zinc-Plated Clear Chromate Finish
Item #: 82335027
Brand: Electro Hardware
Model #: P325M03F21256
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with female threads are internally threaded to accept male fasteners or other standoffs. They are internally threaded on one end.
Brass is an alloy of copper and zinc that is durable, nonmagnetic and conductive.
| Product Specifications | |
|---|---|
| Thread Type | Female |
| Material | Brass |
| System of Measurement | Inch |
| Body Shape | Hex |
| Overall Length (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 0.7500 |
| Thread Size | #2-56 |
| Width Across Flats (Decimal Inch) | 0.1875 |
| Width Across Flats (Inch) | 3/16 |
| Finish/Coating | Zinc-Plated Clear Chromate |
| Body Length (Inch) | 3/4 |
| Thread Depth (Inch) | 3/16 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Fastener Standard | ASTM B633 Type 1; QQ-B-626 Comp 22 |
