Turning Insert
Item #: 82182585
Brand: Tungaloy
Model #: 6802083
Product Specifications
| Insert Style | CNMG |
| Insert Shape Code | C |
| Insert Size Code | 432 |
| Insert Shape | Diamond |
| Clearance Code | N |
| Tolerance Code | M |
| Manufacturer Grade | TH10 |
| Hole Diameter (Decimal Inch) | 0.2030 |
| Maximum Depth of Cut (Decimal Inch) | 0.1575 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Thickness (Decimal Inch) | 0.1870 |
| Corner Radius (Decimal Inch) | 0.0314 |
| Included Angle | 80.0 |
| Series | CNMG |
| Rake | Negative |
| Insert Length (Decimal Inch) | 0.5800 |
| Primary Workpiece Material | Universal |
| Primary Workpiece Material Code | S; H; K; N |
| Iso Code | CNMG432TN38 |
| Standards | ISO |
| Chip Breaker | TN |
| Coating/Finish | Uncoated |
