Brand: Widia / Part #: 2022650

Brand: Widia / Part #: 2022650


Item #: 99761462
Brand: Widia
Model #: 2022650

Product Specifications

Connection Type Arbor
Cutting Width (mm) 10.00
Maximum Depth of Cut (mm) 45.00
Hole Diameter (Mm) ( - 0 Decimals) 40.0000
Cutter Diameter (mm) 160.00
Cutting Direction Neutral
Insert Holding Method Screw
Number Of Cutter Inserts 16
Compatible Insert Style SNHX
Compatible Insert Size Code 06601
Staggered Tooth Yes
Tooth Type Staggered Tooth
Rake Negative
Tool Material Steel
Series M95
Toolholder Style M95
Hub Diameter (mm) 68.000
Tool Application Slotting
Tool Performance General Purpose
Primary Workpiece Material Universal
Minimum Cutting Width (Decimal Inch) 0.3937
Maximum Cutting Width (mm) 10.00
Minimum Cutting Diameter (mm) 160.00
Lead Angle 90
Maximum Body Diameter (mm) 160.00
Cutter Body Width (mm) 10.00
Weldon Flat No
Insert Inscribed Circle (Decimal Inch) 0.5000
Overall Length (mm) 12.0000
Insert Inscribed Circle (Inch) 1/2
Number Of Teeth 8
Coolant Through No
Complete Insert Compatibility SNHX
Coating/Finish Coated
Overall Height (Mm - 5 Decimals) 12.00000
$1,824.91
