Kennametal - DFR020204 MD Grade KCU40 Carbide Indexable Drill Insert - TiAlN Finish, Parallelogram, 2.3mm Inscribed Circle
Item #: 81484594
Brand: Kennametal
Model #: 5065556
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium aluminum nitride (TiAlN) has a higher hardness than TiN and TiCN. It is extremely heat-resistant and used for high-speed applications on stainless steels, nickel and titanium alloys.
| Product Specifications | |
|---|---|
| Insert Style | DFR |
| Insert Size | 020204 |
| Material | Carbide |
| Manufacturer's Grade | KCU40 |
| Inscribed Circle (mm) | 2.30 |
| Thickness (mm) | 2.79 |
| Corner Radius (Inch) | 1/64 |
| Shape | Parallelogram |
| Length (Decimal Inch) | 0.2800 |
| Hole Diameter (mm) | 2.30 |
| Coating | TiAlN |
| Coating Process | PVD |
| Cutting Direction | Neutral |
| Chipbreaker | MD |
