Screw Machine Length Drill Bit: 0.3906″ Dia, 135 °, Carbide Tipped Bright/Uncoated, Right Hand Cut, Spiral Flute, Straight-Cylindrical Shank, Series 115
Item #: 81195257
Brand: CJT
Model #: 11503906
Product Specifications
| Drill Bit Size (Inch) | 25/64 |
| Tool Material | Carbide Tipped |
| Cutting Direction | Right Hand |
| Coating/Finish | Bright/Uncoated |
| Drill Point Angle | 135 |
| Spiral Type | Regular |
| Flute Type | Spiral |
| Point Type | Faceted Split |
| Coolant Through | No |
| Shank Type | Straight-Cylindrical |
| Number Of Flutes | 2 |
| Shank Diameter (Decimal Inch) | 0.3906 |
| Drill Bit Size (Decimal Inch) | 0.3906 |
| Overall Length (mm) | 84.14 |
| Overall Length (Decimal Inch) | 3.3125 |
| Overall Length (Inch) | 3-5/16 |
| Series | 115 |
| Web Thinning | Web-Thinned |
| Web Configuration | Parallel |
| Drill Length Type | Screw Machine |
| Maximum Drilling Depth (Decimal Inch) | 1.1000 |
| Shank Length (Inch) | 1-3/8 |
| Shank Length (Decimal Inch) | 1.3750 |
| Drill Bit Diameter Tolerance | +0.000 to -0.025 mm; +0.0000 to -0.0010 in |
| Flute Length (Decimal Inch) | 1.9375 |
| Flute Length (Inch) | 1-15/16 |
| Flute Length (mm) | 49.21 |
| Drill Bit Size Range (Decimal Inch) | 0.3500 to 0.4000 |
