Milling Insert: OFCR0704TNEML IN2540 TT7080, Solid Carbide
Item #: 44834778
Brand: Ingersoll Cutting Tools
Model #: 5612065
Product Specifications
| Insert Style | OFCR |
| Insert Size | 07 |
| Insert Material | Solid Carbide |
| Insert Shape | Octagon |
| Manufacturer Grade | TT7080 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Number Of Cutting Edges | 8 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1970 |
| Coating/Finish | TiN; TiAlN |
| Relief Angle | 25.00 |
| Insert Size Code | 0704 |
| Material Grade | K05; P25; P05; K25 |
| Inscribed Circle (Decimal Inch) | 0.7060 |
| Thickness Range (Decimal Inch) | 0.1850 to 0.2000 |
| Corner Radius (Inch) | 1/32 |
| Inscribed Circle Range (Decimal Inch) | 0.7000 to 1.0000 |
| Length Range (Decimal Inch) | 0.7000 to 0.9000 |
| Insert Hand | Right Hand |
| Series | OFCR |
| Coating Process | PVD |
| Rake | Positive |
| Primary Workpiece Material | Stainless Steel; Cast Iron; Steel |
| Primary Workpiece Material Code | P; K; M |
| Secondary Workpiece Material | Hard Metals; Cast Iron; Superalloys & Titanium |
| Secondary Workpiece Material Code | S; H; N |
| Ansi Code | OFCR0704TN-EML TT7080 |
| Iso Code | OFCR0704TNEML IN2540 |
| Standards | ISO; ANSI |
| Cutting Edge Style | Corner Rounded |
| Manufacturers Catalog Number | 5612065 |
| Cutter Series Compatibility | 5N2L |
| Chip Breaker | EML |
| UNSPSC Code | 23291601 |
| Material Application | Hard Material; Stainless Steel; Cast Iron; Superalloys & Titanium; Steel |
| Insert Holding Method | Wedge |
| Coating Classification | PVD |
| Single or Double Sided Insert | Single |
| Included Angle Degree | 135 |
| Width (Decimal Inch - 4 Decimals) | 0.7060 |
| Multi-Use Tool | No |
| Length (Decimal Inch - 4 Decimals) | 0.7060 |
