Associated Spring Raymond - 3.05mm OD, 0.46mm Wire, 1/4" Free Length, Compression Spring - 23.49 Lb Spring Rating, 7.07 N Max Work Load, Stainless Steel
Item #: 80063845
Brand: Associated Spring Raymond
Model #: C01200180250S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 6.35 |
| Free Length (Decimal Inch) | 1/4 |
| Spring Rate Pounds per Inch (Pounds) | 23.4900 |
| Maximum Work Load (N) | 7.07000017 |
| Solid Height (mm) | 3.53 |
| Solid Height (Decimal Inch) | 0.1390 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.46 |
| Wire Size (Decimal Inch) | 0.0180 |
