Indexable Square-Shoulder Face Mill: TFE12R125M31.7-10A, 31.7500″ Arbor Hole Dia, Uses 10, SEGW Inserts, Through Coolant, Series TFE
Item #: 79995114
Brand: Tungaloy
Model #: 6748505
Product Specifications
| Minimum Cutting Diameter (mm) | 125.00 |
| Maximum Cutting Diameter (mm) | 125.00 |
| Maximum Depth of Cut (mm) | 8.00 |
| Arbor Hole Diameter (mm) | 31.75 |
| Arbor Hole Diameter (Inch) | 31-3/4 |
| Arbor Hole Diameter (Decimal Inch) | 31.7500 |
| Compatible Insert Size Code | SEGW |
| Maximum Ramping Angle | 0.00 |
| Cutter Style | TFE |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Positive (Radial); Positive (Axial) |
| Rake Angle | 13.0 |
| Series | TFE |
| Overall Height (Mm - 5 Decimals) | 50.00 |
| Keyway Width (mm) | 12.70 |
| Keyway Width (Decimal Inch) | 12.7000 |
| Hub Diameter (mm) | 70.00 |
| Hub Diameter (Decimal Inch) | 70.0000 |
| Hub Diameter (Inch) | 70 |
| Tool Application | Facing |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 10 |
