Indexable Boring Bar: C12-STFCR3, 91.00° N/A Solid Carbide 7.1200″ OAL, Screw,
Item #: 79982468
Brand: Tungaloy
Model #: 6850075
Product Specifications
| Minimum Bore Diameter (Decimal Inch) | 1.0000 |
| Minimum Bore Diameter (Inch) | 1 |
| Maximum Bore Depth (Decimal Inch) | 5.2500 |
| Maximum Bore Depth (Inch) | 5-1/4 |
| Toolholder Style | STFC |
| Tool Material | Solid Carbide |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Shank Diameter (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 7.1200 |
| Overall Length (mm) | 7.12 |
| Compatible Insert Size Code | 32.5 |
| Insert Holding Method | Screw |
| Compatible Insert Shape | Diamond |
| Insert Included | No |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Rake Angle | -6.00 |
| Lead Angle | 91.00 |
| Series | STFC |
| Insert Inscribed Circle (Inch) | 3/8 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
| Compatible Insert Thickness (Decimal Inch) | 0.1560 |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (Decimal Inch) | 0.5850 |
| Primary Workpiece Material | Universal |
| Coolant Through | No |
