Milling Insert: RNHU 1004M4ER-M50 CTPP235, CTPP235, Solid Carbide N/A Finish,
Item #: 79744355
Brand: Ceratizit
Model #: 5113012000
Product Specifications
| Insert Style | RNHU |
| Insert Size Code | 1004 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | CTPP235 |
| Inscribed Circle (Decimal Inch) | 0.3937 |
| Corner Radius (Decimal Inch) | 0.1969 |
| Insert Hand | Right Hand |
| Relief Angle | 0.00 |
| Series | RNHU |
| Coating Process | PVD |
| Hole Diameter (Decimal Inch) | 0.1339 |
| Maximum Depth of Cut (Decimal Inch) | 0.1969 |
| Number Of Cutting Edges | 8 |
| Cutting Edge Effective Length (Decimal Inch) | 0.1968 |
| Insert Shape | Round |
| Rake | Negative |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material | Stainless Steel; Cast Iron |
| Secondary Workpiece Material Code | K; M |
| Ansi Code | RNHU 1004M4ER-M50 CTPP235 |
| Iso Code | RNHU 1004M4ER-M50 CTPP235 |
| Chip Breaker | M50 |
| Coating/Finish | Coated |
| Thickness (Decimal Inch - 4 Decimals) | 0.1811 |
