Kennametal - 200mm Cut Diam, 60mm Arbor Hole, 4.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 16 Inserts, HNGJ 0905ANENLD Insert, Right Hand Cut, 16 Flutes, Through Coolant, Series KSHR
Item #: 77461952
Brand: Kennametal
Model #: 3587732
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 200.00 |
| Cutting Diameter (Decimal Inch) | 7.8740 |
| Arbor Hole Diameter (mm) | 60.00 |
| Arbor Hole Diameter (Decimal Inch) | 2.3622 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 2.4803 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | HNGJ 0905ANENLD |
| Series | KSHR |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1772 |
| Number of Cutter Inserts | 16 |
| Insert Holding Method | Screw |
| Cutter Style | KSHR |
| Number of Flutes | 16 |
| Hub Diameter (Decimal Inch) | 5.1181 |
| Hub Diameter (mm) | 130.00 |
| Maximum RPM | 3180 |
| Cutting Direction | Right Hand |
| Pitch | Coarse |
