Kennametal - HSK100A Taper Shank 3/4" Pilot Diam Shell Mill Holder - 10 Inserts, Insert Style HNGJ 0905, Right Hand Cut, 10 Flutes, Through Coolant, Series Mill 1-18
Item #: 77461929
Brand: Kennametal
Model #: 3325169
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Taper Shank |
| Taper Size | HSK100A |
| Pilot Diameter (Decimal Inch) | 0.7500 |
| Hub Diameter (Decimal Inch) | 3.5433 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | HNGJ 0905ANENLD; HNGJ 0905ANSNGD |
| Arbor Hole Diameter (mm) | 40.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.5748 |
| Cutter Style | KSHR |
| Through Coolant | Yes |
| Series | Mill 1-18 |
| Pitch | Coarse |
| Number of Flutes | 10 |
| Number of Cutter Inserts | 10 |
| Maximum RPM | 5050 |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1772 |
| Lead Angle | 45 |
| Insert Compatibility | HNGJ 0905 |
| Insert Holding Method | Screw |
| Hub Diameter (mm) | 90.00 |
| Cutting Diameter (mm) | 125.00 |
| Cutting Diameter (Decimal Inch) | 4.9213 |
| Overall Height (Decimal Inch) | 2.4800 |
| Overall Height (mm) | 63.00 |
