Kennametal - HSK63A Taper Shank 3/4" Pilot Diam Shell Mill Holder - 9 Inserts, Insert Style HNGJ 0905, Right Hand Cut, 9 Flutes, Through Coolant, Series Mill 1-18
Item #: 77461895
Brand: Kennametal
Model #: 3325166
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Taper Shank |
| Taper Size | HSK63A |
| Pilot Diameter (Decimal Inch) | 0.7500 |
| Hub Diameter (Decimal Inch) | 2.3622 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | HNGJ 0905ANENLD; HNGJ 0905ANSNGD |
| Arbor Hole Diameter (mm) | 27.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.0630 |
| Cutter Style | KSHR |
| Through Coolant | Yes |
| Series | Mill 1-18 |
| Pitch | Medium |
| Number of Flutes | 9 |
| Number of Cutter Inserts | 9 |
| Maximum RPM | 7900 |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1772 |
| Lead Angle | 45 |
| Insert Compatibility | HNGJ 0905 |
| Insert Holding Method | Screw |
| Hub Diameter (mm) | 60.00 |
| Cutting Diameter (mm) | 80.00 |
| Cutting Diameter (Decimal Inch) | 3.1496 |
| Overall Height (Decimal Inch) | 1.9685 |
| Overall Height (mm) | 50.00 |
