Electro Hardware - 2.7 to 3.1mm ID x 4.5mm OD, M2.5 Screw, Grade 101 Nylon Female Unthreaded Circuit Board Spacer - Round Body, Uncoated, 4mm OAL
Item #: 77131985
Brand: Electro Hardware
Model #: MS407M17F16C
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Nylon is a lightweight, nonconductive material resistant to impact, wear and abrasion. It is ideal for electrical applications or where corrosion is a concern.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Nylon |
| System of Measurement | Metric |
| Body Shape | Round |
| Screw Size | M2.5 |
| Outside Diameter (mm) | 4.5 |
| Overall Length (mm) | 4.0 |
| Inside Diameter (mm) | 2.7 to 3.1 |
| Finish/Coating | Uncoated |
| Material Grade | Grade 101 |
| Inside Diameter Tolerance (mm) | 0.000 to 0.270 |
| Length Tolerance (mm) | -0.130 to 0.130 |
| Fastener Standard | MIL-P-17091B |
