Electro Hardware - 3.2 to 3.6mm ID x 6mm OD, M3 Screw, Brass Female Unthreaded Circuit Board Spacer - Round Body, Zinc-Plated Finish, 21mm OAL
Item #: 77129427
Brand: Electro Hardware
Model #: MS1041M01F21D
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Brass is an alloy of copper and zinc that is durable, nonmagnetic and conductive.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Brass |
| System of Measurement | Metric |
| Body Shape | Round |
| Screw Size | M3 |
| Outside Diameter (mm) | 6.0 |
| Overall Length (mm) | 21.0 |
| Inside Diameter (mm) | 3.2 to 3.6 |
| Finish/Coating | Zinc-Plated |
| Inside Diameter Tolerance (mm) | 0.000 to 0.270 |
| Length Tolerance (mm) | -0.130 to 0.130 |
| Fastener Standard | ASTM B633; QQ-B-626 Comp 22; Type 1 |
