Electro Hardware - 3.2 to 3.6mm ID x 6mm OD, M3 Screw, Grade T-3 Aluminum Female Unthreaded Circuit Board Spacer - Round Body, Uncoated, 5mm OAL
Item #: 77126654
Brand: Electro Hardware
Model #: MS1009M04F16D
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Aluminum |
| System of Measurement | Metric |
| Body Shape | Round |
| Screw Size | M3 |
| Outside Diameter (mm) | 6.0 |
| Overall Length (mm) | 5.0 |
| Inside Diameter (mm) | 3.2 to 3.6 |
| Finish/Coating | Uncoated |
| Material Grade | T-3 |
| Inside Diameter Tolerance (mm) | 0.000 to 0.270 |
| Length Tolerance (mm) | -0.130 to 0.130 |
| Fastener Standard | QQ-A-225A Comp 2 |
