Associated Spring Raymond - 12.2mm OD, 1.6mm Wire, 25.4mm Free Length, Compression Spring - 57 Lb Spring Rating, 102.31 N Max Work Load, Music Wire
Item #: 76076702
Brand: Associated Spring Raymond
Model #: C04800631000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 57.0000 |
| Maximum Work Load (N) | 102.30999756 |
| Solid Height (mm) | 12.32 |
| Solid Height (Decimal Inch) | 0.4850 |
| Material | Music Wire |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
