Electro Hardware - M5x0.80, 25mm OAL, 8mm Across Flats, Steel Hex Male/Male Circuit Board Standoffs - 25mm Body Length, Zinc-Plated Finish
Item #: 75251074
Brand: Electro Hardware
Model #: MMX1645M12MSC-1
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with male/male threads are externally threaded on both ends. The ends mate with internally threaded fasteners or other standoffs.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Thread Type | Male/Male |
| Material | Steel |
| System of Measurement | Metric |
| Body Shape | Hex |
| Overall Length (mm) | 25.00 |
| Thread Size | M5x0.80 |
| Width Across Flats (mm) | 8.00 |
| Finish/Coating | Zinc-Plated |
| Body Length (mm) | 25.00 |
| Thread Length (mm) | 9.00; 9.50; 10.00 |
| Length Tolerance (mm) | -0.150 to 0.150 |
| Material Grade | Grade 2 |
| Fastener Standard | QQ-S-633 |
