Electro Hardware - M3x0.50, 10mm OAL, 5mm Across Flats, Stainless Steel Hex Male/Male Circuit Board Standoffs - 10mm Body Length, Passivated Finish
Item #: 75250407
Brand: Electro Hardware
Model #: MMX1415M09-MSC
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with male/male threads are externally threaded on both ends. The ends mate with internally threaded fasteners or other standoffs.
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
| Product Specifications | |
|---|---|
| Thread Type | Male/Male |
| Material | Stainless Steel |
| System of Measurement | Metric |
| Body Shape | Hex |
| Overall Length (mm) | 10.00 |
| Thread Size | M3x0.50 |
| Width Across Flats (mm) | 5.00 |
| Finish/Coating | Passivated |
| Body Length (mm) | 10.00 |
| Thread Length (mm) | 5.00; 6.00 |
| Length Tolerance (mm) | -0.150 to 0.150 |
| Material Grade | 18-8; Grade 303 |
| Fastener Standard | QQ-S-763 |
